FRX Series - Radial Leaded PTC







Application
Wide variety of electronic equipment
Product Features
Low hold current, solid state, radial leaded product ideal for up to 60 Vdc
Operation Current
0.10A~3.75A
Maximum Voltage
Up to 60 Vdc
Temperature Range
-40℃ to 85℃
Agency Recognition
AGENCY AGENCY FILE NUMBER
E211981
E211981
R50004084
Electrical Characteristics (23°C)
Part
Number
Hold
Current
Trip
Current
Max.
Time to Trip
Max
Current
Rated
Voltage
Typ.
Power
Resistance
IH, A
IT, A
@ 5 x IH, s
IMAX, A
VMax, VDC
Pd, W
RMIN
R1MAX
FRX005-60F
0.05
0.10
5.0
40
60
0.26
7.30
20.00
FRX010-60F
0.10
0.20
4.0
40
60
0.38
2.50
7.50
FRX017-60F
0.17
0.34
3.0
40
60
0.48
2.00
8.00
FRX020-60F
0.20
0.40
2.2
40
60
0.41
1.83
4.40
FRX025-60F
0.25
0.50
2.5
40
60
0.45
1.25
3.00
FRX030-60F
0.30
0.60
3.0
40
60
0.49
0.88
2.10
FRX040-60F
0.40
0.80
3.8
40
60
0.56
0.55
1.29
FRX050-60F
0.50
1.00
4.0
40
60
0.77
0.50
1.17
FRX065-60F
0.65
1.30
5.3
40
60
0.88
0.31
0.72
FRX075-60F
0.75
1.50
6.3
40
60
0.92
0.25
0.60
FRX090-60F
0.90
1.80
7.2
40
60
0.99
0.20
0.47
FRX110-60F
1.10
2.20
8.2
40
60
1.50
0.15
0.38
FRX135-60F
1.35
2.27
9.6
40
60
1.70
0.12
0.30
FRX160-60F
1.60
3.20
11.4
40
60
1.90
0.09
0.22
FRX185-60F
1.85
3.70
12.6
40
60
2.10
0.08
0.19
FRX250-60F
2.50
5.00
15.6
40
60
2.50
0.05
0.13
FRX300-60F
3.00
6.00
19.8
40
60
2.80
0.04
0.10
FRX375-60F
3.75
7.50
24.0
40
60
3.20
0.03
0.08



Thermal Derating
Temperature
-40℃
-20℃
0℃
23℃
30℃
40℃
50℃
60℃
70℃
85℃
Derating %
158%
138%
119%
100%
90%
81%
70%
60%
50%
36%

Product Dimension

Fig1

Lead Size: 24AWG

Ø 0.51 mm

Fig 2

Lead Size: 20AWG

Ø 0.81 mm

Part Number
Fig.
A
B
C
D
E
F
Max
Max
Typ
Min
Max
Typ
FRX005-60F
1
7.4
12.7
5.1
7.6
3.1
1.1
FRX010-60F
1
7.4
12.7
5.1
7.6
3.1
1.1
FRX017-60F
1
7.4
12.7
5.1
7.6
3.1
1.1
FRX020-60F
1
7.4
12.7
5.1
7.6
3.1
1.1
FRX025-60F
1
7.4
12.7
5.1
7.6
3.1
1.1
FRX030-60F
1
7.4
13.0
5.1
7.6
3.1
1.1
FRX040-60F
1
7.6
13.5
5.1
7.6
3.1
1.1
FRX050-60F
1
7.9
13.7
5.1
7.6
3.1
1.1
FRX065-60F
1
9.7
14.5
5.1
7.6
3.1
1.1
FRX075-60F
1
10.4
15.2
5.1
7.6
3.1
1.1
FRX090-60F
1
11.7
15.8
5.1
7.6
3.1
1.1
FRX110-60F
2
13.0
18.0
5.1
7.6
3.1
1.4
FRX135-60F
2
14.5
19.6
5.1
7.6
3.1
1.4
FRX160-60F
2
16.3
21.3
5.1
7.6
3.1
1.4
FRX185-60F
2
17.8
22.9
5.1
7.6
3.1
1.4
FRX250-60F
2
21.3
26.4
10.2
7.6
3.1
1.4
FRX300-60F
2
24.9
30.0
10.2
7.6
3.1
1.4
FRX375-60F
2
28.5
33.5
10.2
7.6
3.1
1.4
