FUSB Series - Radial Leaded PTC








Application
Low voltage USB equipment
Feature
Low resistance, Fast trip time, Lower Trip-to-hold Ratio
Operation Current
0.75A ~2.50A
Maximum Voltage
16V/30VDC
Temperature Range
-40℃ to 85℃
Agency Recognition
AGENCY AGENCY FILE NUMBER
E211981
E211981
R50004084
Electrical Characteristics (23°C)
Part Number
Hold
Current
Trip
Current
Rated
Voltage
Max
Current
Typical
Power
Max Time to Trip
Resistance
IH, A
IT, A
VMAX, VDC
IMAX, A
Pd, W
Current
Time
Rmin
R1max
FUSB075F
0.75
1.30
16
40
0.3
8.0
0.4
0.08
0.23
FUSB090F
0.90
1.80
16/30
40
0.6
8.0
1.2
0.07
0.18
FUSB110F
1.10
2.20
16/30
40
0.7
8.0
2.3
0.05
0.14
FUSB120F
1.20
2.00
16
40
0.6
8.0
0.7
0.04
0.14
FUSB135F
1.35
2.70
16/30
40
0.8
8.0
4.5
0.04
0.12
FUSB155F
1.55
2.70
16
40
0.7
7.8
2.2
0.03
0.12
FUSB160F
1.60
3.20
16/30
40
0.9
8.0
9.0
0.03
0.11
FUSB185F
1.85
3.70
16/30
40
1.0
8.0
10.0
0.03
0.09
FUSB250F
2.50
5.00
16/30
40
1.2
8.0
40.0
0.02
0.07



Thermal Derating
Temperature
-40℃
-20℃
0℃
23℃
30℃
40℃
50℃
60℃
70℃
85℃
Derating %
145%
130%
115%
100%
91%
83%
78%
70%
61%
50%

Product Dimension
                                                                                             Product Fig

Fig1

Lead Size: 24AWG

Ø 0.51 mm

Fig 2

Lead Size: 24AWG

Ø 0.51 mm

Part Number
Fig.
A
B
C
D
E
F
Max
Max
Typ
Min
Max
Typ
FUSB075F
2
6.9
11.4
5.1
7.6
3.0
0.8
FUSB090F
1
7.4
12.2
5.1
7.6
3.0
0.8
FUSB110F
1
7.4
14.2
5.1
7.6
3.0
0.8
FUSB120F
2
6.9
11.7
5.1
7.6
3.0
0.8
FUSB135F
1
8.9
13.5
5.1
7.6
3.0
0.8
FUSB155F
2
6.9
11.7
5.1
7.6
3.0
0.8
FUSB160F
1
8.9
15.2
5.1
7.6
3.0
0.8
FUSB185F
1
10.2
15.7
5.1
7.6
3.0
0.8
FUSB250F
1
11.4
18.3
5.1
7.6
3.0
0.8
