FRV Series - Radial Leaded PTC








Application
Line Voltage Power Supply, Transformer and Appliances
Feature
Low hold current, Solid state, Radial leaded product ideal for up to 265VAC/DC
Maximum Operation Current
0.05A~2.00A
Maximum Operating Voltage
240VAC/DC
Maximum Interrupt Voltage
265VAC/DC
Temperature Range
-40℃ to 85℃
Agency Recognition
AGENCY AGENCY FILE NUMBER
E211981
E211981
R50122733
Electrical Characteristics (23°C)
Part Number
Hold
Current
Trip
Current
Rated
Voltage
Max
Current
Max. Int.
Voltage
Typical
Power
Max Time to Trip
Resistance
IH, A
IT, A
VMAX, VAC/DC
IMAX, A
VMAX, V AC/DC
Pd, W
@ 5 x IH, S
Rmin
R1max
FRV005-240F
0.05
0.12
240
1.0
265
0.70
15.0
18.50
65.00
FRV008-240F
0.08
0.19
240
1.2
265
0.80
15.0
7.40
26.00
FRV012-240F
0.12
0.30
240
1.2
265
1.00
15.0
3.00
12.00
FRV016-240F
0.16
0.37
240
2.0
265
1.40
15.0
2.50
7.80
FRV025-240F
0.25
0.56
240
3.5
265
1.50
18.5
1.30
3.80
FRV033-240F
0.33
0.74
240
4.5
265
1.70
21.0
0.83
2.60
FRV040-240F
0.40
0.90
240
5.5
265
2.00
24.0
0.60
1.90
FRV055-240F
0.55
1.25
240
7.0
265
3.40
26.0
0.45
1.45
FRV075-240F
0.75
1.50
240
7.5
265
2.60
18.0
0.32
0.84
FRV100-240F
1.00
2.00
240
10.0
265
2.90
21.0
0.22
0.58
FRV125-240F
1.25
2.50
240
12.5
265
3.30
23.0
0.17
0.44
FRV150-240F
1.50
3.00
240
15.0
265
3.70
23.0
0.12
0.32
FRV200-240F
2.00
4.00
240
20.0
265
4.50
28.0
0.09
0.22



Thermal Derating
Temperature
-40℃
-20℃
0℃
23℃
30℃
40℃
50℃
60℃
70℃
85℃
Derating %
150%
134%
116%
100%
90%
81%
74%
65%
58%
44%

Product Dimension

                                                                                    Product Fig

Fig1

Lead Size: 24AWG

Ø 0.51 mm

Fig 2

Lead Size: 22AWG

Ø 0.65 mm

Fig3

Lead Size: 20AWG

Ø 0.81 mm

Fig 4

Lead Size: 22AWG

Ø 0.81 mm


Part Number
Fig.
A
B
C
D
E
F
Max
Max
Typ
Min
Max
Typ
FRV005-240F
1
8.3
10.7
5.1
7.6
3.8
1.6
FRV008-240F
1
8.3
10.7
5.1
7.6
3.8
1.6
FRV012-240F
1
8.3
10.7
5.1
7.6
3.8
1.6
FRV016-240F
1
9.9
12.5
5.1
7.6
3.8
1.6
FRV025-240F
2
9.6
17.4
5.1
7.6
3.8
1.8
FRV033-240F
2
11.4
16.5
5.1
7.6
3.8
1.8
FRV040-240F
2
11.5
19.5
5.1
7.6
3.8
1.8
FRV055-240F
3
14.0
21.7
5.1
7.6
4.1
1.9
FRV075-240F
3
11.5
23.7
5.1
7.6
4.8
1.9
FRV100-240F
4
18.7
24.4
10.2
7.6
5.1
1.9
FRV125-240F
4
21.2
27.4
10.2
7.6
5.3
1.9
FRV150-240F
4
23.4
30.9
10.2
7.6
5.3
1.9
FRV200-240F
3
24.9
33.8
10.2
7.6
6.1
1.9
